Optical Magnification:165X±10%
Photographic slit width:0.25mm±0.025mm
Cornea thickness measurement accuracy:±0.025mm(>0.6mm)
±0.015mm(≤0.6mm)
Capture Mode:Auto/Semi-Auto/Manual
Capturing positions:The center and 6 peripheral points
Working Voltage:AC220V
Power:100VA
Dimension:360mm*380m*450mm
Weight:25Kg
The function of software:
Analysis values:Number of cells,CD,SD,CV,AVG/Max/Min
Auto/Manual Repair the Cell Edge,Coloring,Magnifying,Automatic Analysis functions,etc
Classification statistic:according to the cell area and cell edges number
Features:
Focus by Double CCD ,it can observe the eyeball and endothelial at the same time.
Non-contact,Fast measuring system,More secure and convenient,The corneal thickness value display
Integrated multiple analysis and measurement tools
Capture Mode:Auto/Semi-Auto/Manual
3D auto focus
Color LCD Touch Screen
7 Capturing positions:The center and 6 peripheral points (2, 4, 6, 8, 10, 12-o'clock positions).
Video printer is optional
Workstaion is optional
USB Data Output
ISO,CE
